YESUN

Module NO. YS-M87631

• LED Type: SMD 3014

• Warranty: 5 years

• Luminous Flux: 25-32lm

• Color:Pure White / Warm White / Cool White

• Suitable for 3 ～8cm depth Narrow Channel Letters

• Waterproof with ABS injection housing

Module NO. YS-M99311

• LED Type: SMD 2835

• Warranty: 5 years

• Luminous Flux: 22-28lm

• Color:Pure White / Warm White / Cool White

• Suitable for 5 ～8cm depth Front Lit & Back Lit Channel Letter.

• Anti-UV, flame-retardant plastic shell

Module NO. YS-M98311

• LED Type: SMD 2835

• Warranty: 5 years

• Power Option: 0.24W or 0.1W

• Chip Grade: High Efficiency Type B or Standard Type A

• Color:Pure White / Warm White / Cool White / Red / Green / Blue

• Suitable for 3 ～10cm depth Channel Letters.

Module NO. YS-M97311

• LED Type: SMD 2835

• Warranty: 5 years

• Power Option: 0.2W or 0.1W

• Chip Grade: High Efficiency Type B or Standard Type A

• Color:Pure White / Warm White / Cool White / Red / Green / Blue

• Suitable for 3 ～10cm depth Channel Letters.

Module NO. YS-M06311

• LED Type: SMD 2835

• Warranty: 3 years

• Luminous Flux: 25-28lm

• Color:Pure White / Warm White / Cool White / Yellow / Red / Green / Blue

• Suitable for 3 ～12cm depth Signage Lighting.

• Fully Customizable for any design

Module NO. YS-M88631

• LED Type: SMD 3014

• Warranty: 5 years

• Luminous Flux: 25-30lm

• Color:Pure White / Warm White / Cool White

• Adopt super high lumen SMD3014 LED,each module can reach 27-30lm

• Adopt aluminum PCB board, good heat sink, long lifespan

Module NO. YS-M08X31

• LED Type: 2-LEDS SMD 1-LED 3014 & SMD2835

• Warranty: 5 years

• Luminous Flux: 30-32lm

• Color:Pure White / Warm White / Cool White

• Smallest dimension ideal for small and thin signage

• ABS injection with transparent PC cover, waterproof IP65

Module NO. YS-M81221

• LED Type: SMD3528

• Warranty: 5 years

• Luminous Flux: 20lm

• Color:Pure White / Cool White / Red / Green / Blue

• Waterproof with injection housing

• Suitable for 6～12cm depth signs such

Module NO. YS-M82231

• LED Type: SMD3528

• Warranty: 5 years

• Luminous Flux: 25-30lm

• Color:Pure White / Cool White / Red / Green / Blue

• Single module as a unit can be cut accordingly

• Maximum module quantity per string up to 20pcs
